VMC650 3 Axis Hard Line Vertical Milling Machining Center For Mold Process
| TY-650 vertical / hard rail | |
| Table size (MM) | 420 x 800 |
| X-axis travel (MM) | 650 |
| Y-axis travel (MM) | 400 |
| Z-axis travel (MM) | 480 |
| Maximum table load (KG) | 600 |
| T-slot(slot number×width×pitch) (MM) | 3-18-135 |
| Spindle power (KW) | 7.5 |
| Maximum spindle speed (RPM) | 8000 |
| Rapid traverse (X/Y/Z) (mm/min) | 20000 |
| Cutting feed (mm/min) | 2-8000 |
| Spindle nose to table (MM) | 80-560 |
| Spindle center to column surface distance rail (MM) | 480 |
| Positioning accuracy (MM) | ±0.005/300 |
| Repeat accuracy (MM) | ±0.003/300 |
| Screw Type | 3206 |
| TOOL type | BT40 |
| ATC type | ARM |
| Maximum tool weigh (KG) | 6 |
| Dimensions (MM) | 2300*2000*2500 |
| Machine weight (KG) | 4000 |
We Provide One Year Warranty And Free Component In Guarantee Time
MOQ is one sets.
Yes. We are CNC machine tool manufacturer, we can design and manufacture according to your specific requirements.
Taiye CNC machine tools are high performance and best price. We have more than 15 years high tech CNC machine tool manufacture experience, high research and development capabilities, a production team of up to 200 people, we have more than 10 patents for CNC product technology, making our machine tools more competitive Taiye CNC machine tool are use our own fool like system which is easy to use and max to save to labor
Please tell me your specifications and leave your contact information to us,we can choose the best model for you , or you can choose the exact model . You can also send us the products drawing ,we will choose the most suitable machines for you .
Taiye Machinery equipment Company are locate in Yuhang district, Hangzhou City, Zhejiang Province, China, and Our Guangdong office are in Nanhang district, Foshan city. If you come to China, you can contact us and we can pick you up at the airport or station.
